NdFeB Magnet Bonded by Pressing
Bonded magnet is produced by compression molding of compound alloy powder with epoxy resin, and it can also be made by injection or extrusion from alloy powder mixed with plastic,
NdFeB Magnet Bonded by Pressing
Bonded magnet is produced by compression molding of compound alloy powder with epoxy resin, and it can also be made by injection or extrusion from alloy powder mixed with plastic, we call it NdFeB injection magnet.
YX MAGNETIC SA offers:
Protype by machining : feasibility verification.
Creation of mold for mass production : guarantees the homogeneity of the parts.
Combination with plastic or metal parts by injection molding
High precision dimension and good consistency with stable magnetic property.
Quote NowGet Catalog
TECHNICAL DATA
| Type of process | Grade | Max. energy product (BH)max. [kJ/m3] |
Residual Induction Br. [mT] |
Coercivity Hcb [kA/m] |
Intrinsic Coercivity Hcj [kA/m] |
Max. operating temp. ② MTC [℃] |
|---|---|---|---|---|---|---|
| Injection NdFeB magnet | BIN-2+PPS | 12~20 | 260~350 | 160~240 | 400~560 | <180 |
| Compression moulding NdFeB magnet | BCMN-2 | 24~32 | 400~500 | 240~320 | 480~640 | 160 |
| BCMN-4 | 32~40 | 450~550 | 240~320 | 480~640 | 160 | |
| BCMN-6 | 48~56 | 550~650 | 320~400 | 520~680 | 160 | |
| BCMN-7 | 56~64 | 600~700 | 320~400 | 520~680 | 160 | |
| BCMN-8 | 64~72 | 600~700 | 400~480 | 640~800 | 160 | |
| BCMN-8H | 64~72 | 600~700 | 400~480 | 880~1040 | 160 | |
| BCMN-9 | 68~76 | 620~720 | 400~480 | 640~800 | 160 | |
| BCMN-9H | 64~72 | 650~730 | 400~480 | 640~800 | 160 | |
| BCMN-10 | 72~80 | 670~750 | 416~496 | 640~800 | 160 | |
| BCMN-10H | 72~80 | 670~750 | 416~496 | 640~800 | 160 | |
| BCMN-12 | 76~88 | 680~770 | 440~520 | 720~880 | 160 | |
| BCMN-13 | 80~96 | 700~800 | 400~560 | 640~800 | 160 | |
| Compression moulding NdFeB magnet | BIN-4+PPS | 28~36 | 300~550 | 240~400 | 440~600 | <180 |
| BIN-5+PPS | 36~44 | 450~550 | 280~440 | 640~800 | <180 | |
| BIN-5+PPS | 36~44 | 450~550 | 280~440 | 800~960 | <180 | |
| BIN-6+PPS | 44~52 | 450~600 | 280~440 | 640~800 | <180 | |
| BIN-2+Nylon12 | 12~28 | 250~390 | 168~248 | 240~400 | <120 | |
| BIN-4+Nylon12 | 28~44 | 390~510 | 248~320 | 400~560 | <120 | |
| BIN-6+Nylon12 | 44~56 | 510~600 | 320~384 | 640~800 | <120 | |
| BIN-8+Nylon12 | 56~68 | 600~680 | 384~432 | 640~800 | <120 |
